RO Pre Filtration PHFM 6.6㎡ High Flow Filter Cartridge

Name: RO Pre Filtration PHFM 66 High Flow Filter Cartridge
Brand: PULLNER
Price: 1 USD

Brand Name : PULLNER

Model Number : PHFM

Certification : FDA

Place of Origin : Shanghai China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal

Supply Ability : 1500pcs per week

Delivery Time : 3-7days

Packaging Details : Carton box after poly bag. 4pcs per carton

OD : 6"

Length : 20", 40", 60"

Material : PP, PET, Glass Fiber

Filtration rating : 1um, 2um, 5um, 10um, 15um, 20um, 30um, 50um, 70um, 100um

Filtration area : 6.6㎡

MOQ : 1 piece

Delivery time : 7 days

Sample : Free

OEM : Yes

Origin : Shanghai

Contact Now

Top Selling Products In Google High Flow Filter Cartridge

Performance Specifications

Dimensions

Diameter	6.5" (160mm)
Length	20" (508mm)
	40" (1016mm)
	60" (1524mm)

Material of Construction:

Model	Filter Medium	Support/Drainage	End Caps	Seals Material
PP	Deep pleated Polypropylene	Polypropylene	Glass Fiber Reinforced Polypropylene	NBR, Silicone, EPDM, Viton
PET	Polyester	Polyester	Glass Fiber Reinforced Polypropylene	NBR, Silicone, EPDM, Viton

Filter Performance

Micron	1um, 3um, 5um, 10um, 15um, 20um, 50um, 70um, 100um
Max. operating temperature	82℃
Max. operating differential pressure	3.44bar@82℃
Suggestion pressure for filter replacement	2.5Bar@20℃
Max. flow rate	20": 35m³/h
	40": 70 m³/h
	60": 110 m³/h

General Description

PHFM series high flow filter cartridge is made of diameter 6.5" and PP pleated design with big flow area and dirt holding capacity. All connection use thermal welding. It can meet different flow requirements, with a wide range of chemical compatibility, can be applied to various fields.

Application:

RO pre-filtration, desalination pretreatment;

Power plant condensation water filtration;

Biopharmaceutical industry pharmaceutical raw materials, solvents, water filtration;

Food and Beverage process water treatment;
